AXS2 Aquatic Lift

AXS2 Aquatic Lift

The aXs2 Aquatic Lift is a low-profile solution designed for community, aged-care, and rehabilitation swimming pools, providing easy access. The lift is installed in the pool deck via a locking anchor and has a lifting capacity of 136 kg. The aXs2 operates using a 24v battery-powered screw-driven actuator, featuring full mechanized left, right, up, and down motion with a 360-degree rotation. The system’s design and durability ensure consistent operation while minimizing service problems.

Maintenance of the aXs2 lift is virtually hassle-free, with its components made from corrosion-resistant materials, including powder-coated stainless steel and aluminum construction. The lift’s unique seat was designed with the user’s safety, comfort, and ease of transfer in mind. The hand control is water-resistant and allows the user or attendant to operate it with ease, with a 360-degree rotation. The LiftOperator control box and battery are also water-resistant.

The standard, molded plastic footrest is removable and floats upwards to prevent damage if the user lowers the chair too low over the deck.

What’s Included:
aXs2 Lift, Hand Controller, Deck Anchor, Footrest, Arm Rests, Battery Charger, Battery Cover and Seat Belt Assembly.

How to Operate:
To use the aXs2 lift, the user first accesses the seat, and then uses the left and right buttons on the hand controller to rotate the lift over the pool. The up and down button can then be used to raise or lower the seat. When finished, the user can simply float off the seat, and getting out is just as easy.

Installation:
The aXs2 lift is typically installed by attaching it to the pool deck using a square deck anchor that is cored into the pool deck.

Shipping Dimensions:
Ctn 1 140 x 48 x 36cm (L x W x H) 46kg
Ctn 2 61 x 61 x 69cm (L x W x H) 16kg

    Select Size

    aXs2 Aquatic Lift N/A
    Spine Board Attachment N/A
    Extra Deck Anchor (multiple locations) N/A
    Stability Strap (for new seat design) N/A
    LiftOperator Control Unit N/A
    Charger (LiftOperator) with Adaptor N/A
    Battery for LiftOperator N/A
    Hand Controller (4 Way) N/A
    Pool/Spa Lift Available On Request 230mm x 300mm Metal Sign N/A
    Brand: SR Smith,
    Type: Spa and Pool Accessibility Equipment,
    Availability:

    Out of stock
